Product Details:
|
Application: | Roadway Safety | Material: | Q235 Q345 |
---|---|---|---|
Zinc Coating: | 550-600g/㎡,Customized | Color: | Customized Color |
Certificate: | CE/BV/ISO 9001/ISO14001/ISO | Standard: | AASHTO M-180 |
Usage: | Outdoor Security | Technology: | Hot Galvanized+cold Rolled |
Product Name: | Highway Guardrail | Surface Treatment: | Galvanized + Powder Coated |
Port: | Qingdao, Tianjin Port, China |
American AASHTO-M180 Technical Standard W-beam highway guardrail | ||||||||
TYPE | Overall Length (mm) | Effection Length (mm) | Norminal Uncoated Thickness (mm) | |||||
TYPE Ⅰ | 4130 | 3810 | 2.67 | |||||
TYPE Ⅱ | 4320 | 4000 | 2.67 | |||||
MECHANICAL PROPERTIES | ◆Material grade: S355JR ◆Yield Point, minimum, 345Mpa (50000psi); ◆Tensile Strength, minimum 483Mpa (70000psi); and ◆Elongation, in 50mm (2 in.),minimum, 12 percent. | |||||||
NOTES | ●Thickness of Zinc coating: 550g/㎡ or1100g/㎡; ●The beams may galvantzed before or after fabrication; ●We can customize the length and thickness according to customer requirements. |
