Roadway Safety Highway Barrier With CE Certification And Q235 Q345 Steel

Roadway Safety Highway Barrier With CE Certification And Q235 Q345 Steel
Roadway Safety Highway Barrier With CE Certification And Q235 Q345 Steel Roadway Safety Highway Barrier With CE Certification And Q235 Q345 Steel Roadway Safety Highway Barrier With CE Certification And Q235 Q345 Steel Roadway Safety Highway Barrier With CE Certification And Q235 Q345 Steel Roadway Safety Highway Barrier With CE Certification And Q235 Q345 Steel Roadway Safety Highway Barrier With CE Certification And Q235 Q345 Steel

Large Image :  Roadway Safety Highway Barrier With CE Certification And Q235 Q345 Steel

Product Details:
Place of Origin: Shandong, China
Brand Name: Safebuild
Payment & Shipping Terms:
Minimum Order Quantity: 20 pieces
Price: $50.00/pieces 20-199 pieces
Packaging Details: 100 pieces/pack or as required by customer
Supply Ability: 250000 Piece/Pieces per Year
Contact Now

Roadway Safety Highway Barrier With CE Certification And Q235 Q345 Steel

Description
Product Name: UPN 120 Post For Guardrail Material: Q235 Q345
Application: Roadway Safety Surface Treatment: Hot Dippe Galvanized
Certificate: CE/ISO 9001/ISO14001/ISO 18001 Feature: Easily Assembled
Keyword: Highway Guardrail Post Standard: JT/T281/AASHTO M180
Package: 100pcs/ctn Usage: People Safe
Port: Qingdao Tianjin Shanghai, Port China
Highlight:

ce guardrail barrier

,

w beam guardrail barrier

,

roadside guardrail barrier

Product Overview



HIGHWAY GUARDRAIL
Steel beam guardrail is a kind of road crash barrier used for securing highway safety by preventing errant vehicles from sliding out of the roads and impacting the roadside buildings or other objects. So it is most commonly fixed on the side of the highways, dock areas, aisles, especially on curves and slopes for protection against run-off-road collisions.There are mainly two specifications of steel guardrail: W-Beam guardrail and Thrie-Beam guardrail, They are manufactured from Q235B or Q345B grade steel in 2.5-4mm base metal thickness as supplied by China Steel Limited. All products are hot dipped galvanized or powder coated after fabrication to meet the requirements of Chinese National Standards, AASHTO M180 Standard, SANA 1350 Standard and etc.
Roadway Safety Highway Barrier With CE Certification And Q235 Q345 Steel 0
Roadway Safety Highway Barrier With CE Certification And Q235 Q345 Steel 1
FEATURES AT A GLANCE
Roadway Safety Highway Barrier With CE Certification And Q235 Q345 Steel 2
American AASHTO-M180 Technical Standard W-beam highway guardrail



TYPE
Overall Length
(mm)
Effection Length
(mm)
Norminal Uncoated Thickness
(mm)
TYPE Ⅰ
4130
3810
2.67
TYPE Ⅱ
4320
4000
2.67
MECHANICAL
PROPERTIES
◆Material grade: S355JR
◆Yield Point, minimum, 345Mpa (50000psi);
◆Tensile Strength, minimum 483Mpa (70000psi); and
◆Elongation, in 50mm (2 in.),minimum, 12 percent.


NOTES
●Thickness of Zinc coating: 550g/㎡ or1100g/㎡;
●The beams may galvantzed before or after fabrication;
●We can customize the length and thickness according to customer requirements.



PRODUCT SPECIFICATIONS
Item
Data
Solar cell
(monocrystalline silicon) 2.5V/ 120mAh
Working time
72 hours for 8 hours at a time;
Energy storage element
Rechargeable battery 1.2V/ 600mAh
Material
cast aluminum alloy shell + bulletproof PC
Working environment
-20℃ ~ 70℃;
Starting light intensity
positive light is less than 500Lux;
Display colors
red, yellow, white, blue and green
Visual distance
greater than 1000m
PRODUCT CONFIGURATION
Roadway Safety Highway Barrier With CE Certification And Q235 Q345 Steel 3

Roadway Safety Highway Barrier With CE Certification And Q235 Q345 Steel 4

Roadway Safety Highway Barrier With CE Certification And Q235 Q345 Steel 5

Roadway Safety Highway Barrier With CE Certification And Q235 Q345 Steel 6
Roadway Safety Highway Barrier With CE Certification And Q235 Q345 Steel 7
Roadway Safety Highway Barrier With CE Certification And Q235 Q345 Steel 8
Manufacturing Technique
Roadway Safety Highway Barrier With CE Certification And Q235 Q345 Steel 9
Roadway Safety Highway Barrier With CE Certification And Q235 Q345 Steel 10
Roadway Safety Highway Barrier With CE Certification And Q235 Q345 Steel 11
SIMILAR PRODUCTS
Roadway Safety Highway Barrier With CE Certification And Q235 Q345 Steel 12
Roadway Safety Highway Barrier With CE Certification And Q235 Q345 Steel 13
Roadway Safety Highway Barrier With CE Certification And Q235 Q345 Steel 14
Company Profile
Roadway Safety Highway Barrier With CE Certification And Q235 Q345 Steel 15
Roadway Safety Highway Barrier With CE Certification And Q235 Q345 Steel 16
Roadway Safety Highway Barrier With CE Certification And Q235 Q345 Steel 17
Shandong Safebuild Traffic Facilities Co.,Ltd was established in 2015. It is located in Liaocheng City, Shandong Province, China. We specialise in manufacturing and exporting Highway Guardrail and other accessories such as traffic safety products.
Our company has an advanced production line of plastic spraying and hot-dip galvanizing for guardrail . According to the
different construction environment, and corresponding surface treatments can be adopted to achieve good corrosion resistance, moisture resistance and weather resistance. We also specialise in the production of guardrail accessories like reflectors and other road safety products such as road suds.
Our aim is to Safebuild people, with our professional, wholehearted and devoting spirits as well as our remarkable products quality and favorable service system , sincerely hope to work together with the vast number of clients!
FAQ
1.Q:Are you a factory or trading company?
A:We are factory which has been in this field for more than 10 years.

2.Q:Where is your factory located? How can I visit there?
A:Our factory is located in Liaocheng City, Shandong Province, China. All our clients, from home or abroad, are warmly welcome to
visit us!

3.Q:How can I get some samples?
A: We are honored to offer you samples. Please send a sample inquiry and leave us your email address, then we will send you more
information about the samples for your reference.

4.Q:How does your factory do regarding quality control?
A:Quality is priority. All our staff members always attach great importance to quality controlling from the very beginning to the
very end. Our factory has gained ISO 9001 and SGS authentication.
