Hot Dipped Galvanized Steel Highway Guardrail H Post Anti corrosion

Certification
China Shandong Safebuild Traffic Facilities Co., Ltd. certification
China Shandong Safebuild Traffic Facilities Co., Ltd. certification
I'm Online Chat Now

Hot Dipped Galvanized Steel Highway Guardrail H Post Anti corrosion

Hot Dipped Galvanized Steel Highway Guardrail H Post Anti corrosion
Hot Dipped Galvanized Steel Highway Guardrail H Post Anti corrosion Hot Dipped Galvanized Steel Highway Guardrail H Post Anti corrosion Hot Dipped Galvanized Steel Highway Guardrail H Post Anti corrosion Hot Dipped Galvanized Steel Highway Guardrail H Post Anti corrosion Hot Dipped Galvanized Steel Highway Guardrail H Post Anti corrosion Hot Dipped Galvanized Steel Highway Guardrail H Post Anti corrosion

Large Image :  Hot Dipped Galvanized Steel Highway Guardrail H Post Anti corrosion

Product Details:
Place of Origin: Shandong, China
Brand Name: Safebuild
Payment & Shipping Terms:
Minimum Order Quantity: 25 tons
Price: $750.00/tons 25-199 tons
Packaging Details: Export standard bundle or as clients request
Supply Ability: 2500 Ton/Tons per Year

Hot Dipped Galvanized Steel Highway Guardrail H Post Anti corrosion

Description
Product Name: H Post For Highway Guardrail Material: Q235 Q345
Application: Roadway Safety Usage: Road Traffic Safe
Surface Treatment: Hot Dippe Galvanized Feature: Anti-corrosion
Keyword: Highway Guardrail Post Certificate: ISO9001:2000
Port: Qingdao, Tianjin Port, China
Highlight:

hot dipped galvanized highway guardrail

,

h post highway guardrail

,

h post steel highway guardrail

Products Description
Hot Dipped Galvanized Steel Highway Guardrail H Post Anti corrosion 0



High strength hot dip galvanizing H post for highway guardrail
H-beam is a kind of economical section with more optimized section area distribution and more reasonable strength-weight ratio. It is named because its section is the same as the English letter "H". Due to the right-angle arrangement of all parts of H-beam, h-beam has been widely used for its strong bending resistance, simple construction, cost saving and light structural weight in all directions. An economic section shaped like a capital Latin letter H, also known as universal steel beam, wide flange (edge) I-steel or parallel flange I-steel.
The cross-section of h-beam steel usually consists of a web and a flange, also known as the waist and the side. The flange of h-beam is parallel or close to the plane, flange ends are at right angles, hence the name of the parallel flange
I-steel. The web thickness of H-beam is smaller than the ordinary I-steel with the same height of the web, and the flange width is larger than the ordinary I-steel with the same height of the web, so it is also named wide flange I-steel.
Determined by the shape, the section modulus, moment of inertia and corresponding strength of H-beam are obviously superior to ordinary I-beam with the same single weight. When used in different metal structures with different requirements, it shows its superior performance no matter under bending moment, pressure load and eccentric load, and can greatly improve the bearing capacity compared with ordinary I-steel, saving 10%~ 40% of the metal.
H-beam has wide flange, thin web, many specifications and flexible use, which can save 15% ~ 20% of metal in all kinds of truss structures. Because the flange inside and outside is parallel, the edge end is a right Angle, easy to assemble and combine into various components, thus can save about 25% of the workload of welding, riveting, can greatly accelerate the construction speed of the project, shorten the construction period.
Hot Dipped Galvanized Steel Highway Guardrail H Post Anti corrosion 1
Hot Dipped Galvanized Steel Highway Guardrail H Post Anti corrosion 2
With H post is to use a guardrail according to customer's demand, h-beam manufactured after cutting, punching, this kind of barrier post of simple structure, convenient installation, whether under bending moment, pressure load and eccentric load are show its superior performance, can effectively prevent the moving vehicles are not out, reduce the happening of the accident.
One end of the H-shaped post is fastened with bolts and connecting pieces and guardrail, and the other end is buried in the earth, which plays a supporting role in road guardrail and can effectively prevent vehicles from rushing out.
H-type post is generally used in conjunction with H-type block, U-type block, brackets, etc. It is simple in structure and easy to install. Formed by hot rolling, high strength, high hardness, at the same time the surface generally do hot galvanizing treatment, corrosion resistance, long life.
Details Images
Hot Dipped Galvanized Steel Highway Guardrail H Post Anti corrosion 3
Hot Dipped Galvanized Steel Highway Guardrail H Post Anti corrosion 4
Hot Dipped Galvanized Steel Highway Guardrail H Post Anti corrosion 5
Product Paramenters
Hot Dipped Galvanized Steel Highway Guardrail H Post Anti corrosion 6
Name
H Post for highway guardrail
Material
Q235B/Q345B
Surface Treatment
Hot Dipped Galvanized
zinc Coating
70-85μm
specifications
120*55*7.0*9.0
150*100*4.3*5.5
Standard
JT/T281/AASHTO M180
Process
Hot rolled steel
MOQ
20MT
Advantages of H channel galvanized steel posts for highway guardrail:
* Fully hot dip galvanized to AS/NZS4680.
* Superior performance, High strength, high hardness
* Easy transportation, storage and handling
* Long life and durability
* Simple design
* Cost effective
Installation Instructions
Hot Dipped Galvanized Steel Highway Guardrail H Post Anti corrosion 7
Hot Dipped Galvanized Steel Highway Guardrail H Post Anti corrosion 8
Hot Dipped Galvanized Steel Highway Guardrail H Post Anti corrosion 9
Hot Dipped Galvanized Steel Highway Guardrail H Post Anti corrosion 10
Hot Dipped Galvanized Steel Highway Guardrail H Post Anti corrosion 11
Hot Dipped Galvanized Steel Highway Guardrail H Post Anti corrosion 12
Hot Dipped Galvanized Steel Highway Guardrail H Post Anti corrosion 13
Hot Dipped Galvanized Steel Highway Guardrail H Post Anti corrosion 14
Hot Dipped Galvanized Steel Highway Guardrail H Post Anti corrosion 15
